22 FIRE 4-12X40 T-PLEX Rimfire Rifle Scope

The memories of days spent in the squirrel woods are ones we all treasure. So when designing our rimfire rifle scope, we aimed to create something that would truly elevate the performance of modern rimfire cartridges.

CA $334
Adding to cart… The item has been added
SKU
3
UPC:
856012006031

Performance Grade Optics

Direct from the Manufacturer

Precision Engineering

No Markup Added

Personalized Support

Details and Specs

This 4-12x40 22 FIRE scope has the optical qualities of a high-powered centerfire rifle scope though it’s specifically designed for the rimfire. For example, the parallax is set at 75 yards with 1/4" adjustments at 50 yards. The stage is set for performance and fun that only a rimfire topped with a 4-12x40 22 FIRE can provide. Customize your 4-12x40 22 FIRE rimfire rifle scope with an Impact Custom Turret allowing you to dial in the distance for long range shooting.



Discover top-quality Rifle Scopes Binoculars Precision Gear Designed for hunters, shooters, and outdoor enthusiasts seeking precision and clarity. Visit our blog!



T-Plex Reticle

T-Plex Reticle

With this T-Plex reticle, we have eliminated the thick top vertical post to open up the reticle and provide a cleaner, less obstructed view of the target. The thickness in the horizontal and bottom vertical posts still allows for fast target acquisition. The point of the bottom thick post is strategically placed to provide bullet drop compensation for various distances based on the cartridge you are shooting. Simply use the IMPACT ballistic program to determine your maximum point blank range, bottom post distance and other crucial aspects that will make you a more accurate shooter.

Main Body Tube

Main Body Tube

The one-inch, two-piece tube is O-ring sealed and purged with argon gas, making it completely waterproof and fogproof.

Fully Multi-Coated Technology

Fully Multi-Coated Technology

TRACT'S Fully Multi-Coated (FMC) optical system applies multiple layers of anti-reflective compounds to every air to glass surface to provide extremely high light transmission with bright, clear images even in low light.

Magnification Ring

Magnification Ring

The super-smooth magnification ring, with rear facing numbers easily allows you to zoom from low to high power.

Windage and Elevation Adjustment Knobs

Windage and Elevation Adjustment Knobs

Hand Turn windage and elevation adjustments with precise, repeatable and audible 1/4" clicks at 50 yards are easily reset to zero without any tools, making sighting in or field adjustments quick and easy. Customize your riflescope with an Impact Custom Turret allowing you to dial in the distance for long range shooting.

T-Plex Reticle

T-Plex Reticle

The T-Plex reticle takes the standard Plex type reticle to another level by eliminating the thick top vertical post, creating a cleaner field of view while still allowing your eye to quickly find the center crosshair for fast target acquisition.

Spring Loaded Reset to Zero

Spring Loaded Reset to Zero

Simply lift the turret, turn to line up the zero with the vertical indicator, release and the turret springs back into place

Quick Focus Eyepiece

Quick Focus Eyepiece

Easily and quickly allows you to focus the sharpness of the reticle

Waterproof and Fogproof with Argon Gas

Waterproof and Fogproof with Argon Gas

Fully waterproof and Fogproof using O-Ring seals and purged with Argon gas which has a higher resistance to temperature changes versus the Nitrogen used in many other competitor's products.

Rimfire Rings (not included)

Rimfire Rings (not included)

Don't forget to add rimfire rings to your 22 FIRE scope order. Manufactured by WARNE, these solid steel rings are the perfect compliment to your 22 FIRE riflescope. Fits a wide selection of rifles with either a 3/8″” or 11mm dovetail. NOT INCLUDED

TRACT Trust Assurance Warranty

TRACT Trust Assurance Warranty

The TRACT Trust Assurance guarantees the functionality of the product for the duration of its lifetime regardless of whether you’re the original owner. No time limit applies and no paperwork is needed.

Magnification 4-12X
Objective Lens Diameter 40mm
Eye Relief (inches) 3.5 / 3.5
Exit Pupil 10 / 3.3
Field of View (@1,000 yards) 341 feet
Field of View (Low Power/High Power in feet @ 100 yards) 23.5 / 7.8
Relative Brightness 11.11
Twilight Factor 21.9
Diopter Range +/- 3
Length (inches) 13.9
Weight (ounces) 16
Internal Adjustment Range (MOA) 60
Click Value (MOA) .25 at 50 yards
Tube Diameter 1 inch (two piece)
Reticle Type Electro-formed Copper Wire
Coatings Fully Multi-coated
Recoil Shock Endurance 1,000g
Operating Temperature Range 158°F to -1.4°F
Internal Charge Argon Gas
Parallax Setting 75 yards
Finish Black Matte
Reticle Focal Plane 2nd
Eyepiece Outside Diameter 1.74 inches
Objective Outside Diameter 1.8 inches
Objective Diameter (millimeters) 40
Mount Space 5.9 inches
Waterproof Depth (meters) 3
Butler Creek Flip Up Cover Objective Size 25 (not included)
Butler Creek Flip Up Cover Eyepiece Size 19 (not included)
Country of Origin Philippines
